PROBE OF THE MONTH JULY 2018

                           A Q-Mark Exclusive!

This ultralight M2 right angle stylus holder is a Q-Mark exclusive.  It's used to measure internal grooves and perpendicular bores.  Before this ultralight holder, CMM users were forced to use star hubs or knuckle joints with threaded styli to achieve right angle probing.  Multiple parts were required, adding weight and limiting clearance.  Our ultralight holder weighs just 2.40 grams and allows the use of our full array of unthreaded styli.  Because no additional parts are needed, it's more rigid, and far less expensive than conventional setups.  It will reach into tight spaces with ease, simplifying part set-up and programming.



The part numbers are PH2-10 for 1.0 mm styli, and PH2-15 for 1.5 mm styli.  Both are in stock at $45.00 each. A hex wrench is included (shown).

We look forward to seeing you at IMTS in September!

Booth 135501
